2pcs Winsen WPCK03 Diffussed Silicon Pressure Transmitter Multi Output Methods Excellent Anti-interference Ability

$59.00
Application: Process control system,Pressure calibration instrument,Hydraulic system,Biomedical instruments,Hydraulic system and valve,Liquid level measurement,Military equipment,Refrigeration equipment and HAVC system,Ships and navigation,Pipeline pressure monitoring
Feature: Stainless steel consturcture,Wide temperature compensation-10~+70℃,Multi output methods,Excellent anti-interference ability,High reliability,Hi Accuracy,Low consumption

FREE
SHIPPING

100% MONEY
BACK GUARANTEE

ONLINE
SUPPORT 24/7

Availability: 198 In Stock
Categories: Flow Sensors & Pressure Sensors, Pressure sensor, Pressure sensors

Production Description:
WPCK03 series diffused silicon pressure sensor is a pressure transmitter integrated with high-precision imported diffused silicon pressure sensitive chip and packaged with mature production process sensor as a signal measuring element, integrates highly reliable signal processing circuit and wide temperature compensation. At the same time, this product has undergone strict testing and screening of components, semi-finished products and finished products, which maintain high precision standard signal output at different temperatures. The product has excellent reliability, flexibility and diversity, it's widely used in pressure measurement and monitoring of water affairs, IoT, chemical industry, petroleum and other industries. This product has multi output methods, which can meet different technical requirements of customers in different applications. Our company can customize pressure transmitters with different appearances and functions according to customer requirements to provide customers with more reliable solutions.
Feature:
  • Stainless steel d4sturcture
  • Wide temperature compensation-10~+70℃
  • Multi output methods
  • Excellent anti-interference ability
  • High reliability
  • Hi Accuracy
  • Low consumption

Application:

  • Process control system
  • Pressure calibration instrument
  • Hydraulic system
  • Biomedical instruments
  • Hydraulic system and valve
  • Liquid level measurement
  • Military equipment
  • Refrigeration equipment and HAVC system
  • Ships and navigation
  • Pipeline pressure monitoring

Main technical parameters:

Basic Parameter Index

Pressure range

-100kPa～0～10kPa…100MPa


Pressure Reference

GaugePressure/AbsolutePressure/Sealed Gauge Pressure


Power supply

3.3V-5.5VDC (Or others)


Working Current

＜3mADC


Output

I²C(Pressure/Temperature)、4-20mA、

0.5-4.5V and others


Accuracy

±0.2%FS,±0.5%FS

Can be customized

Low Consumption

Standby current＜100nA


Temperature Error

±2℃

Only for I²C mode

Pressure Error

±0.25%FS

Only for I²C mode

input resistance

≤（U-12）/0.02Ω(2-wire system)、

≥10k（3-wire system）

Only for analogue signal mode

Overload

1.5 or 2.0 times full scale


TemperatureCompensation

-10～70℃


Working Temperature

-40～80℃


Storage Temperature

-25～85℃


Vibration Resistance

10gRMS，20～2000Hz


Shock Resistance

100g, 11ms


 Sealing

FKM


Housing material

316L


DiaphragmMaterial

316L


Plug

Standard PH2.0-5P


Reverse polarity protection

Yes

In voltage output mode power supply and output cannot be reversed
